Compressed Air Amplifier Applications
Typical Compressed Air Amplifier Applications replace fans, used for blow-off, cleaning, drying, cooling and conveying:
Automotive:
Remove water, coolant, dust, and scrap in parts manufacturing and in assembly operations. Cool enamel and water based paints in parts manufacturing, auto body shops or assembly lines.
Bottling:
Blow off of water from the tops of cans, some or some bottles prior to labeling, ink jetting, palletizing or packaging. Conveying light materials.
Chemicals:
Blow off of chemicals or water prior to labeling or packaging as with bottling.
Food:
Remove water from product or packaging.
General Manufacturing:
Part ejection, fume removal, dust and liquid blow off from all types of parts, conveying away waste, ideal for replacing fans in some cooling operations such as tempering glass.
Metals:
Coolant and other liquid removal on process lines from Aluminum, Steel, Brass or other materials. Dry metals prior to other operations such as plating or polishing. Cool metal parts prior to coating or painting. Coolant mist removal. Boost vacuum systems to remove grinding dust. Cool steel forgings.
Paper & Lumber:
Sawdust removal and control by boosting the vacuum system, dust removal. Trim removal in converting applications.
Plastic:
Dust and scrap blow off. Cool moldings after extrusion, then blow off and dry prior to forming.
Printing:
Cooling to set some inks, scrap blow off.
Pharmaceutical:
Remove liquid prior to labeling or packaging waste removal for solid materials. Extract unfilled capsules by vacuum as they pass on a conveyor.
Textile:
Scrap and trim removal on textiles to eliminate expensive vacuum systems.
|
